1 Year Warranty
AudioControl LC-6.1200 High Power Multi Channel Car Amplifier with Accubass
- Availability:In Stock
- Available:5 in stock
- Item Condition:New
- Brand:AudioControl
- Product Code:LC-6.1200
- EAN / UPC:7427307014654
- Warranty:1 Year Warranty
£859.99
LC-6.1200 Multi Channel Amplifier
Building from the hugely successful LC-4.800 multi-channel amplifier, the LC-6.1200 is surely the most flexible 6 channel amplifier on the market. Featuring eight active speaker level inputs with summing, coupled with an intuitive three-way Linkwitz-Riley crossover network, the LC-6.1200 can be easily integrated with most factory installed source units. The patented AccuBASS® circuit compensates for factory bass roll-off and provides maximum bass performance.
More control and features include our GTO Signal Sense, MILC Source Clip Detection and assignable Remote Level Control. The LC-6.1200 builds on the legacy of audio passion and a focus on user-friendly features, making this a perfect solution based amplifier.
Features
- Configurable as 6/5/4/3/2 channel amplifier
- 6 x 200 watts @ 2 ohms
- 6 x 125 watts @ 4 ohms
- 400 watts @ 4 ohms bridged
- AccuBASS® Processing
- MILCTM Maximum Input Level Control (Patent Pending)
- GTOTM Signal Sense
- 3-way Independent Linkwitz-Riley Alignment crossovers
- Summable active speaker-level inputs (8 channels) for OEM integration
- 6 preamp inputs
- 2 assignable preamp outputs
- PFM Subsonic Filter
- Optional ACR-1 assignable remote control
- Solid One-Piece Aluminum Chassis
Specifications
Inputs
- Preamp Inputs
- 6 balanced
- Preamp Input Voltage Range
- 250 mV – 8 Vrms
- Speaker Level Inputs
- 8
- Speaker Level Input Voltage Range
- 3 V – 40 Vrms
Outputs
- Rated Continuous (RMS) Power at 14.4V:
- 4 Ω – 125 W x 6 RMS
- 2 Ω – 200 W x 6 RMS
- Bridged 4 Ω – 400 W RMS
- Preamp Outputs
- 2
- Maximum Preamp Output
- 8.5 V RMS
Performance
- Frequency Response
- 10 Hz – 30 kHz
- Signal to Noise
- 102 dBa, Ref 200 W @ 2 Ohm
- THD+N
- < 0.1%
- Minimum Power / Ground Wire Gauge
- 3 AWG wire
- Fuse Rating
- 3 x 40 A
- Crossover
- 3-way Linkwitz-Riley, Adjustable From 30 Hz – 5000 Hz
Weights & Dimensions
- Dimensions
- 12″W x 8.0″D x 2.1″H
- Weight
- 7.2lbs. (3.3kg)
In The Box
- LC-6.1200
- Speaker connectors
- Fuses
- Manual
- Warranty
